SOLAR TYPE:

AOL: MS-2KP

Introducing our Solar Powered Medium Intensity Type B Aviation Obstruction Light – a high performance solution for power transmission lines and telecommunication towers. This light utilizes high brightness SMD LED technology, flashing in red color, with a PMMA automotive grade lens for optimal light distribution.

Complying with ICAO and CAAM regulations, our Solar Powered Medium Intensity Type B model guarantees reliable and efficient aviation safety for structures above 45 meters.

Download Brochure PDF

Everything you should know about our AOL: MS-2KP

Engineered for Visibility. Built for Compliance. Proven in Real-World Applications.

Features

10Cd Brightness

IP67 Rating

Surge Protection

Power
Savings

Solid State Tech

Photo Sensor

Battery Powered

Solar Energy

20 - 60 Flashing

Compliance

ICAO

CAAM

SIRIM

Application

Building

Telecom Towers

Transmission Line

Specifications

Engineered to Meet Standards. Designed for Reliable Performance

Compliance and Certifications

ICAO Annex 14.
CAAM ASD 404 & CAD 14
FAA L-864

**Dimension (LWH) & Weight**

266x266x98mm (Lamp Head)
584x345x166mm (Casing Assembly)
1.8kg (Lamp Head)
4.2kg (Solar Panel)
3.0kg (24V Battery Set)

Performed Test

Rain Test - 130mm/h
Wind Test - 150km/h
Humidity Test - 95% RH (+55˚C for 72h)
Operational Test - 1000h
Leakage Current Test - < 10µA
Lightning Surge Test - 6kV 1.2/50μs, 3kA 8/20μs

Characteristics

Light Type - Medium Intensity Type B
Light Source - 80 SMD LED
Lifespan - ≥ 100,000h
Effective Intensity - 2000 Cd (Night)
Light Color - Red
Horizontal Beam - 360˚

Vertical Beam - >10˚

Operation

Mode - Flashing
Flashing Rate - 20 - 30 fpm
Temperature: -20˚C ~ +60˚C
IP Rate - IP67
Battery Autonomy - MPPT SLA: Up to 6 days MPPT LiFePO4: Up to 8 days

Material

Cover - Automotive Grade PMMA
Body - ED Coated Die Cast Aluminum
Battery Compartment - Stainless Steel
Base Frame - Aluminum
Solar Panel Type - Monocrystalline
